It is our panel group designed as Surface Mounted Wall type.
Wall Mounted Panels, are panel systems that are generally used for various purposes such as floor panels, meter panels, apartment panels in Production Facilities, Residences, Offices, Hospitals and similar facilities, enabling the distribution and control of electrical energy in smaller areas and at the same time maintaining smaller electrical systems.
| Feature | Applicable Feature |
|---|---|
| Application Types | With Mounting Plate (MP), Curtain Sheet (PS), Meter Cover (SP) |
| Protection Class | Up to IP65 |
| Framework | Monoblock Welded 1/1,2mm DKP |
| Plinth | Semi Modular Welded 1.5mm DKP |
| Impact Rating/IK Code | IK10 |
| Gasket Type | Liquid Polyurethane Cast Gasket |
| Color Code | Electro Static Powder PaintRAL 7035W |
| Optional Features | POC Series Tempered Glass |
| POP Series Plexiglass Glass | |
| PO Series External Top Roof | |
| PO Series Recessed Frame | |
| PODDOK Wall Additional Front Door | |
| PODDPP Serial Wall Curtain Sheet Set | |
| PODD15 Series 1.5mm Body and Cover | |
| PODD20 Series 2mm Body and Cover | |
| PORAL Series Paint Ral Code Change | |
| POA5 Serial Sheet A5 Project Pocket | |
| PO Series 60x30x30 cm Field Type Stand | |
| PO Series 60x30x30 cm Field Type Modular Stand | |
| PO Series 60x40x30 cm Field Type Socket Cover Stand | |
| PO Series Semi-Modular Leg Set | |
| PO Series Metal Scissor Lid Stopper |
